Dungs MB-DLE 412 B07 S22
Multibloc
- Single Stage
- Main Volume Restrictor
- Adjustable Opening Behaviour
- 412 = DN32, V2 = Double-seat Valve
- B07 – two A valves for main gas, one A valve together with V1 as internal bypass around V2 + regulator
- Outlet Pressure 0.4-2 kPa (4-20 mbar)
- Inlet Pressure – up to 36 kPa (360 mbar)
- S22 – V1 and V2 Separate Operation
Possible Flange Sizes: Rp 3/4″, Rp 1″ or Rp 1 1/4″
